Mercedes-Benz GLC : Tire pressure / Tire pressure table
The tire pressure table is on the inside of the
fuel filler flap.
The data shown in the images is example
data.
If one or more tire sizes precede a tire pressure,
the following tire pressure information is only
valid for those tire sizes and their respective
load condition.
The load conditions "partially laden" and "fully
laden" are defined in the table for different numbers
of passengers and amounts of luggage. The
actual number of seats may differ from this.
Some tire pressure tables only show the rim
diameter instead of the complete tire size, e.g.
R18. The rim diameter is part of the tire size and
can be found on the tire side wall.
- Tire and Loading Information placard
- Maximum tire pressure
WARNING Risk of accident due to insufficient
or excessive tire pressure
Tires with either too low or too high a pressure
present the following hazards:
the tires could burst
the tires could wear excessively and/or unevenly
the driving characteristics as well as steering and braking
characteristics may be severely impaired
Observe the recommended
tire pressures
and check the tire pressure of all
tires including the spare wheel:
monthly
if altering the load on the vehicle
prior to long journeys
if the operating conditions change, for
example when driving off-road
Adjust the tire pressure
where necessary...
Read the tire pressure
recommended for the
current operating conditions from the Tire
and Loading Information placard or the tire
pressure table. Observe the notes on tire
pressure...
Other information:
Requirements:
The electric parking brake is released.
ESP® is activated and is not intervening.
The transmission is in position
.
The driver's door is closed.
Check of the radar sensor system has been
successfully completed.
Parking Assist PARKTRONIC is not being
used to park the vehicle or to exit from a
parking space...
The vehicle is not suitable for the use of tow bar
systems that are used for flat towing or dinghy
towing, for example. Attaching and using tow bar
systems can lead to damage on the vehicle.
When you are towing a vehicle with tow bar systems,
safe driving characteristics cannot be
guaranteed for the towing vehicle or the towed
vehicle...
